Complete Waveform Breakdown
*Detailed anatomy of the Sinus Rhythm cycle.*
1. The "Sinus" Family
A Sinus Rhythm means the heart's natural pacemaker (SA Node) is functioning correctly. The rhythm is regular, and every P-wave is followed by a QRS.
| Wave | Action | Description |
|---|---|---|
| P-Wave | Atrial Squeeze | Small bump. Top chambers contracting. |
| QRS | Ventricular Squeeze | Tall spike. Bottom chambers contracting. |
| T-Wave | Recovery | Heart resetting for next beat. |
- Normal Sinus Rhythm (NSR): Rate is standard (60–100 bpm).
- Sinus Tach (Tachycardia): Normal rhythm, but fast (>100 bpm).
- Sinus Brady (Bradycardia): Normal rhythm, but slow (<60 bpm).
2. Atrial Fibrillation (A-Fib)
The Story: The top chambers are "quivering" rather than squeezing effectively.
- No P-Waves: Baseline is wavy/chaotic.
- Irregularly Irregular: The spacing between spikes varies unpredictably.
3. Premature Ventricular Contraction (PVC)
The Story: An electrical "misfire" from the ventricles.
- Wide & Bizarre: The beat is wider and taller/deeper than normal.
- No P-Wave: It happens too early for atrial contraction.
⚡ Summary Cheat Sheet
| Rhythm | P-Waves? | Pattern |
|---|---|---|
| Sinus | Yes, uniform | Regular |
| A-Fib | None (wavy) | Irregularly Irregular |
| PVC | None on extra beat | Early, Wide & Bizarre |
